VR 22-E “GIP”
Walk Behind Rollers:
DESCRIPTION
The Walk Behind Roller model VR 22-E “GIP” is a manually driven roller with double hydraulic traction and insertion of the vibration activated by electromagnetic transmission and belts.
Suitable for compacting asphalt or granular surfaces. The extremely compact frame allows you to work almost flush with the wall.
Thanks to an effective cooling radiator, it was possible to use a few liters of oil in the hydraulic circuit, allowing it to be used in any environmental condition.
Ergonomic control handle
The convenient controls positioned on the handle allow to activate the vibration, to change the compaction force and to establish the direction of travel.
45 liter water tank
The large diameter of the filling hole makes it easily accessible for cleaning.
Central attachment point
Easy and safe lifting and handling
Full engine coverage
Guarantees maximum engine protection
TECHNICAL SPECIFICATIONS
MODEL | DRUM width / diam. | weight | transmission | vibration | fuel | engine | |
---|---|---|---|---|---|---|---|
VR 22E | 650 mm / 400 mm | 716 kg | hydraulic | electromagnetic | DIESEL | Kohler 15LD440 Hatz 1B40 | 8,0 kW (10,9 HP) 7,4 kW (10 HP) |
Model | drum width / diam. | weight | transmission | vibration | fuel | engine |
---|---|---|---|---|---|---|
VR 22E | 650 mm / 400 mm | 716 kg | hydraulic | electromagnetic | DIESEL | Kohler 15LD440 – 8,0 kW (10,9 HP) Hatz 1B40 – 7,4 kW (10 HP) |
ACCESSORIES
Technical documentation and CE certificate are always included.
